P2102A PDN Probe
2 Port 50 Ω Transmission Line PDN Probes
Enhance your PDN measurement results with PICOTEST probes. The PICOTEST PDN probes are precision passive 50 Ω transmission line “browser” probes that support a variety of measurements. Due to their sophisticated design, they have significant advantages in comparison overactive probes and other types of passive probes.
Key Features
- PDN probes support measuring of
- Non-invasive Stability (NISM)
- Impedance (1 port or 2 port impedance)
- PCB resonances
- Step-Load & Ripple
- Various attenuation ratios for optimum sensitivity and SNR (1x, 2x, 5x or 10x)
- Virtually no capacitive loading
- 50 Ω impedance
- Wide bandwidth
- Reduces the risk of damaging the fine copper pads of circuit boards
- Rugged, ergonomic design, small form factor gets into tight places
Download
Video
PDN Impedance Measurements using the Bode 500 and Picotest PDN Probes
